UP-242GS-M2

UP-242GS-M2 is a high-performance Layer 2 (L2) managed Ethernet switch. It includes 24 ports operating at 10/100/1000 Mbps and 2 SFP ports operating at 1000 Mbps.

Contact

Description

UP-242GS-M2 is a high-performance Layer 2 (L2) managed Ethernet switch. It includes 24 ports operating at 10/100/1000 Mbps and 2 SFP ports operating at 1000 Mbps. All ports support Storage-and-Forward mode. Combined with dynamic memory usage, this increases the efficiency of bandwidth allocation and resource optimization. UP-242GS-M2 supports port-based VLANs and protocol-based VLANs allowing for network segmentation and data manipulation, respectively. The switch works with the Spanning Tree Protocol (STP / MSTP), which improves the fault tolerance and helps to ensure stable network operations. Additionally, the UP-242GS-M2 switches support the Access Control Lists (ACL) that account for the time and the day of week. Support of 802.1x authentication, based on the port and MAC address, helps customers to improve network security and prevents unauthorized access from unknown devices. Optimal QoS strategy and a wide range of VLAN features make UP-242GS-M2 an invaluable piece of equipment for small-to-medium businesses, hotels, and campus area networks. PoE features are supported for IEEE 802.3at-compliant class 4 powered devices (PD), UP-242GS-M2 switches automatically detect each PD’s power consumption and deliver up to 30 watts over Cat 5,6 cables with 25.5 watts available to devices. The switch tracks its power budget (PoE budget) of 380W and grants power only when it is available.

  • Complies with IEEE 802.3i, IEEE 802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.1q, IEEE802.1p
  • 24 x 10/100/1000Mbps Auto MDI/MDI-X RJ-45 ports
  • 2 x 1000Mbps SFP ports
  • Supports IEEE802.3at/ IEEE802.3af PoE standards
  • Delivers up to 30W to PDs, PoE budget up to 380W
  • 8K MAC address table with auto-learn option and automatic aging
  • PoE port management
  • IEEE802.3x Flow Control
  • Port Mirroring
  • Store-and-Forward Mode
  • Jumbo Frames 9216 Byte
  • LED indicators for PoE and Link / Activity/Speed
  • SSH/ Telnet/ Web-based Management

Specifications

General features

Standard

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.3at, IEEE 802.3af, IEEE 802.1q, IEEE 802.1p

Addition

Width

440 mm (17.32 inches)

Height

44 mm (1.69 inches)

Depth

208 mm (8.18 inches)

Switch

The number of switch ports

24 x 10/100/1000 RJ45 Ports, 2 x 1000Mbps SFP ports, 1 x Console port

PoE

24 x RJ-45 ports compliant with IEEE802.3at/af;
power pin assignment: a-mode, pins 1 and 2 (V+), pins 3 and 6 (V-)

PoE budget

380W

PoE management

on/off, port status, temperature alarm

MAC address table

8K

Jumbo Frame

9216 Bytes

Packet Buffer

38.69 MPPS

Switching Capacity

4.1Mbit

Packet Forwarding Rate

38.69 MPPS

Transfer Method

10Mbps - 14,880 PPS; 100Mbps - 148,800 PPS; 1000Mbps - 1,488,000 PPS

DHCP

Client

Port Mirroring

One to One/ Many to One

NTP/LLDP

No/No

Security

Username / Password protection; ACL (MAC-Based, IPv4-Based), DHCP Snooping (IP, MAC, Port), DoS attacks prevention, MAC filtering, IP Source Guard, Port Isolation

802.1q VLAN

802.1Q VLAN

QoS

Number of Priority queue: 8 queues/ port; Scheduling for priority queue: RR/SP/WRR/WFQ; Port based QoS, IEEE 802.1p Class of Service (CoS), DSCP-based QoS

LACP

Static; Max. Group: 5; Max. Ports/Group: 8

IGMP Snooping

No

Spanning Tree

STP; MSTP

Storm Control

Broadcast/ Multicast/ Unknown Unicast

Monitoring and Management

Web management interface

Yes

Telnet connection

Yes

SNMP v1/v2c/v3

Yes

SSH v2

Yes

Command Line Interface (CLI)

Yes

ACL for SNMP/Web/SSH/Telnet

Yes

Event/Error Log

Yes

Software Download/ Upgrade

Yes

Configuration Download / Upload

Yes

Remote Ping

Yes

RMON (1,2,3, & 9 groups)

Yes

Further information

Power

100-240VAC /50-60Hz 260W, maximum consumption 435W

LED indicators

Power, Link/Activity/Speed, PoE (per port)

Operating Temperature

0℃ to 45℃ (32 °F to 113°F)

Storage Temperature

-40℃ to 70℃ (-40 °F to 158°F)

Operating Relative Humidity

10% to 90% (non-condensing)

Package Contents

UP-242GS-M2 switch, mounting brackets kit, AC power cord, User Manual

Certificates

CE, FCC, EAC
